YGO GBA Hacking with Hex Maniac Advance (Eternal Duelist Soul/WCT06)

[Yak Attack]

Here is an example of what can be done, currently.



[Yak Attack]

Partial HMA TOMLs for 5 YGO GBA games have been uploaded:
- Eternal Duelist Soul
- Reshef of Destruction
- WCT04
- 7 Trials to Glory: WCT05
- Ultimate Masters: WCT06



[Yak Attack]

Card images/palettes (and card icons) have been found in Ultimate Masters:

510640: 0x12C0 byte card graphics (6bpp)
4C76C0: 0x80 byte card palettes
FBC080: 0x600 byte card icon images (8bpp)
13264C0: 0x240 byte card icon images (8bpp)
510440: 0x120 byte card icon palette

each card graphic is 0x12C0 long and uses 6bpp. each card palette is 0x80 bytes long. alt arts screw up the order, it's in the same order as the card indexes except for that tho. card icons are 8bpp. the smaller card icons have a right-side-up version and a sideways version apiece. the card icons use one pal that is 0x120 long.



[Yak Attack]

A C injection for inserting images ripped from YGOProDeck in mass has been made for Ultimate Masters. Also, card name sorting by alphabetical order is now possible, and I was able to save some more free space by only making it work for English text. I would update the file in the drive, but it has 2 new cards, so I don't think that would be fitting. I'll update it later.

Oh, and I made some updates to the TOML and HMA itself, including linking related fields, finding cards through the "Show Uses" button, and card icon graphics:




Found two new effects tables, too.



[HandlessPhantom]

Screenshots:

Ultimate Masters: World Championship Tournament 2006

View attachment 174051

The Eternal Duelist Soul

View attachment 174053

TOMLs

Hello. I dont seem to understand how to get to this screen. I have the hex maniac advance application and the Eternal Duelist rom. I see that there are some files at the end of this post but i am not sure what to do with those. I am not familiar with romhacking so I don't know how to navigate my way around these programs if someone can help me understand.



[Yak Attack]

Hello. I dont seem to understand how to get to this screen. I have the hex maniac advance application and the Eternal Duelist rom. I see that there are some files at the end of this post but i am not sure what to do with those. I am not familiar with romhacking so I don't know how to navigate my way around these programs if someone can help me understand.

Hi,

The TOMLs will be updated soon. Did you download the TOML for EDS? If so, make sure it's in the same folder as the EDS ROM, and named the same.



[Yak Attack]

New TOML update for WCT06 includes the attribute/race graphics and removes the Windows PRNG algorithm from the passwords (so you can use raw passwords).
